Ocean Green (RB18-HD) Vinyl Wrap

Description

Our Gloss Metallic vinyl wrap has a smooth, high-gloss finish and is crafted from the high-grade polymeric multilayered calendared vinyl film, complete with air release channels.  Gloss Metallic wrap is durable and has good conformability; it’s stretchable enough to wrap around every edge and recessed area of your vehicle with ease.  Gloss Metallic also uses a safe solvent polyacrylate adhesive, easy to install, and is gentle on car paint.

Specifications

Conformable polymeric material with stable color pigments. Suitable for full car wrapping (or any other smooth or curved surface).

The thickness of the film(um): 122
The thickness of the release liner(um): 142

Note: Products that have "HD" letters in their SKU (product code) are with the plastic release liner (high-gloss films)

Type of film: High-grade polymeric multilayered calendared vinyl film with air-release channels

Width & Length: Standard roll size - 1.52m*18m (59.8"* 708,6", 4.98ft*59ft, 1.66yd* 19,6yd)

Series: 190 series

Adhesive: Henkel solvent-based acrylic adhesive, transparent, ultra-weather-resistant, viscosity 1000~3000cps, thickness 12 µm dry
001)

Storing period (shelf life): 2 years if stored at +10°C to +20°C, with a relative humidity of 50%, in the original package, away from direct sunlight, clean and dry place

Durability/Warranty: Datasheet (Click the link)

Application: from +17°C to +18°C, usage from -45°C to +45°C

Release force (N/25mm): Standart: 0.10-0.30, Result:0,17 (23?,54%H)

Initial Tack(g/25mm): Testing method: GB31125-2014: Standart 800-1500, Result: 840 (23?,54%H)

180° Peel strength (N/25mm): Testing Method: GB/T2792-1998: Standart =6.8, Result: 8,7 (23?,54%H)

Adhesion strength: Testing method: GB/T4851-1998, Standart =60, Result 70 (No shifting)

Aging (65?, 7 days): Standart - High-temperature release without adhesive residue, result: no adhesive residue

Aging (-65?, 10 days): Standart - Low-temperature release without adhesive residue, result: no adhesive residue

Recommended application tools: Squeegee, buffer, knife, masking tape, heat gun, magnets, gloves, IRR thermometer, IRR heater

Application method: Standard methods for calendered films. No overstretching. Post heating

Post-heating temperature: 100°C

Cure time: 24 hours above 10°C

Aftercare: PH neutral, Avoid wax or solvents

Directional: Yes

Tools: soft squeegees with buffers

The protective cap should be peeled off before installation.

Important note: The images, colors, and finishes on the screen are approximate. For the real representation of the product, always check the color swatch. Rolls from the same production LOT number should be used for completing a wrap job as a slight batch-to-batch variation of color may occur. The film may scratch during the application or a day in and out use. The scratching of the film is not covered by the warranty.
