Stylish Matte Dark Carbon Fiber Vinyl

With a collection of different styles, TeckWrap offers you this carbon fiber series that gives your vehicle a stylish finish with a genuine look. As a proud supplier, TeckWrap has plenty of film selections with good conformability and durability. The material is stretchable enough to wrap every edge and recessed area easily. Designed for interior and exterior applications.

Polymeric Film Specs & Installation Info

Reliable polymeric PVC for partial application. Designed for wrapping smooth surfaces or elements of medium difficulty in wrapping, such as spoilers, mirrors, etc.

The thickness of the film is 0.13 mm.
The thickness of film with release liner: 0.29mm
Type of film: High-grade polymeric calendered vinyl film with air release channels
Colors: Black

Series: 180 series
Adhesive: Henkel solvent-based acrylic adhesive, transparent, ultra-weather-resistant, viscosity 1000~3000 cps, thickness 12 µm dry
Release liner: Felix Schoeller Release Liner / 20-104-20-1.9 printed, double-sided PE-coated Kraft. One side solventless silicone-coated, air release (ISO 9001, ISO 14001, OHSAS 18001)
Storage period: 2 years if stored at +10° to +20°, relative humidity 50%, in original package, away from direct sunlight, in a clean and dry place.
Durability/Warranty: ? Datasheet (Click the link)
Application: from +5° to +30°, usage from -30° to +45°
Dimensional stability: shrinkage of less than 2%
Plastification: between 28% and 28%-38%
Breaking Strength: 23.7 N/10mm (Average) Test Method: ASTM D3759/D3759M-05 6.4 N/10mm (Average) Test Method: ASTM D3330/D3330-04
Light Ageing in UV Exposure: Test Method: ASTM D4329-13 Cycle A & ISO 105-A02:1993/Cor.2:2005, Test result: 3-4 Exposure cycle: ASTM D4329-13 cycle A, Lamp type: UVA-340 8 h UV at (60±2.5)? BPT, 0.89 W/(m²•nm)@340 nm, 4 h condensation at (50±2.5)? BPT, Exposure duration: 44h

Post-heating: 95 Celsius

Package: Roll width is 152, length 18 m, weight 14 kg
